3/8 in. Drive 6mm 12-Point Tether-Ready Socket
J5206M-TT
3/8 in. Drive 6mm 12-Point Tether-Ready Socket
- Proto® Tethered Tool Sockets are manufactured with four detent holes so that the pin detent will engage correctly regardless of the direction the socket is placed on the square drive
- The Positive Control System requires a separate tool to attach or remove the socket, meaning it cannot be removed without specific intent
- Chrome finish is applied after the holes are bored for better corrosion resistance
Additional Features
- Proto® 12 point sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
- The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners
| SKU | Product Name | Nut End Outside Diameter [Imperial] | Drive End Outside Diameter [Imperial] | Nut Depth [Imperial] | Bolt Clearance Depth [Imperial] | Overall Length [Imperial] | Product Weight [Imperial] | Purchase |
|---|---|---|---|---|---|---|---|---|
| J5210M-TT | 3/8 in. Drive 10mm 12-Point Tether-Ready Socket | 19/32 in | 43/64 in | 5/16 in | 45/64 in | 1-3/32 in | 0.06 lbs | |
| J5215M-TT | 3/8 in. Drive 15mm 12-Point Tether-Ready Socket | 27/32 in | 27/32 in | 17/32 in | 7/16 in | 1-1/8 in | 0.1 lbs | |
| J5214M-TT | 3/8 in. Drive 14mm 12-Point Tether-Ready Socket | 25/32 in | 25/32 in | 15/32 in | 7/16 in | 1-1/8 in | 0.08 lbs | |
| J5223M-TT | 3/8 in. Drive 23mm 12-Point Tether-Ready Socket | 1-3/16 in | 1-3/16 in | 47/64 in | 5/8 in | 1-5/16 in | 0.21 lbs | |
| J5217M-TT | 3/8 in. Drive 17mm 12-Point Tether-Ready Socket | 15/16 in | 15/16 in | 17/32 in | 7/16 in | 1-1/8 in | 0.12 lbs | |
| J5206M-TT | 3/8 in. Drive 6mm 12-Point Tether-Ready Socket | 25/64 in | 43/64 in | 1/4 in | 45/64 in | 1-3/32 in | 0.05 lbs | |
| J5219M-TT | 3/8 in. Drive 19mm 12-Point Tether-Ready Socket | 1 in | 1 in | 17/32 in | 1/2 in | 1-3/16 in | 0.14 lbs | |
| J5220M-TT | 3/8 in. Drive 20mm 12-Point Tether-Ready Socket | 1-3/32 in | 1-3/32 in | 5/8 in | 1/2 in | 1-3/16 in | 0.17 lbs | |
| J5213M-TT | 3/8 in. Drive 13mm 12-Point Tether-Ready Socket | 47/64 in | 47/64 in | 9/32 in | 1/2 in | 1-1/8 in | 0.07 lbs | |
| J5208M-TT | 3/8 in. Drive 8mm 12-Point Tether-Ready Socket | 27/64 in | 43/64 in | 1/4 in | 45/64 in | 1-3/32 in | 0.05 lbs | |
| J5225M-TT | 3/8 in. Drive 25mm 12-Point Tether-Ready Socket | 1-21/64 in | 1-21/64 in | 49/64 in | 5/8 in | 1-3/8 in | 0.29 lbs | |
| J5224M-TT | 3/8 in. Drive 24mm 12-Point Tether-Ready Socket | 1-1/4 in | 1-1/4 in | 49/64 in | 37/64 in | 1-5/16 in | 0.23 lbs | |
| J5218M-TT | 3/8 in. Drive 18mm 12-Point Tether-Ready Socket | 61/64 in | 61/64 in | 17/32 in | 1/2 in | 1-3/16 in | 0.12 lbs | |
| J5207M-TT | 3/8 in. Drive 7mm 12-Point Tether-Ready Socket | 15/32 in | 43/64 in | 1/4 in | 45/64 in | 1-3/32 in | 0.06 lbs | |
| J5209M-TT | 3/8 in. Drive 9mm 12-Point Tether-Ready Socket | 33/64 in | 43/64 in | 9/32 in | 45/64 in | 1-3/32 in | 0.05 lbs | |
| J5226M-TT | 3/8 in. Drive 26mm 12-Point Tether-Ready Socket | 1-21/64 in | 1-21/64 in | 49/64 in | 59/64 in | 1-3/8 in | 0.26 lbs | |
| J5212M-TT | 3/8 in. Drive 12mm 12-Point Tether-Ready Socket | 45/64 in | 45/64 in | 9/32 in | 1/2 in | 1-1/8 in | 0.05 lbs | |
| J5211M-TT | 3/8 in. Drive 11mm 12-Point Tether-Ready Socket | 41/64 in | 43/64 in | 21/64 in | 45/64 in | 1-3/32 in | 0.07 lbs | |
| J5216M-TT | 3/8 in. Drive 16mm 12-Point Tether-Ready Socket | 55/64 in | 55/64 in | 17/32 in | 7/16 in | 1-1/8 in | 0.1 lbs | |
| J5221M-TT | 3/8 in. Drive 21mm 12-Point Tether-Ready Socket | 1-3/32 in | 1-3/32 in | 9/16 in | 41/64 in | 1-9/32 in | 0.18 lbs | |
| J5222M-TT | 3/8 in. Drive 22mm 12-Point Tether-Ready Socket | 1-11/64 in | 1-11/64 in | 43/64 in | 5/8 in | 1-5/16 in | 0.22 lbs |
